Camera Inputs

No of PoE

16 x 10/100

Max. # of Channels

32

Protocols

ONVIF

Performance

30fps@4K2K/CH, 4Mbps/CH

Live Display

Performance

Realtime Display with the D1/VGA 2nd Stream of Camera

-Main: Up to 4K2K 30fps

-Sub: Up to D1 960fps

Recording

Performance

Main: 960fps@4K2K +

Sub: 960fps@D1/VGA

Codec

Video: H.264 / H.265

Audio: G.711 (A Law / U Law)

Monitor Output

Main Monitor

Up to 4K30 for HDMI and Up to 1080p60 for VGA

Multiple Ch View

1,4,8,9,10,16,20,25,32 for both live and playback

Audio In/Out

-

1 Line-in /1 Line-out & Audio on HDMI

Alarm In/Out

-

8 In/1 OUT

Storage

SATA

5

Archive

Backup Device

USB Device (HDD, Thumb Drive), NAS/FTP & Remote via Network

Multiple channel

Raw data format, Support with the Embedded Player

AVI

Embedded AVI formatting

USB Port

-

1 x USB2.0 at Rear & 1 x USB2.0 at Front

Camera Control

-

One RS485 port

System Control

-

USB Mouse / Web menu / Remote on the Web browser

Network

Port

10/100/1000 Ethernet + 10/100/1000 PoE + 15 x 10/100 PoE

Protocols

DHCP, DDNS, P2P, uPNP, HTTP, NTP, SNMP, SMTP, Push Notification(iOS/Android), ONVIF(Client)

No of Client

Max. 4

Network Service

-

ns.ddns2.gixel.kr/P2P server/Relay Server/Push Server/E-mail (Public server)

Network Streaming

Live

Playback

Selectable Stream from IP Camera (Main/Sub)

Dual Streaming

Multi-Language

-

Support

RAID(Mirroring)

-

Configurable Dual Recording

Search

-

Calendar/Slide Bar/Virtual Jog Shuttle/Event/Panorama/Smart/USB Backup Device

Event

Event Type

Motion Detection, Alarm in, Video Loss, HDD S.M.A.R.T Status, HDD Error, Recording Status, POS(TBD)

Notification

Action

E-Mail with snapshot, Buzzer, Pop-up, Symbol, Push Notification

PoS I/F

-

Extendable up to 8 PoS Interface (Customizable)

Health Checking & Report

-

Periodical E-mail Report for HDD&Recording Status with various system information

Remote SW’s

-

RMS / Web / Android / iOS / JavaScript+WASL / macOS

Power

Inputs

48V-4.58A(220W)

PoE(802.3af)

~180W

Operating Env.

-

-5~45°C  / 20~80% RH

Dimension (WxDxH, mm)

-

430x400x68
