Woohyeon Digital

Live Display (NTSC/PAL)

~1080p

1440p

1944p

2160p

Realtime (480/400fps)

Realtime (480/400fps)

1944p (320fps)

2160p (240fps)

Recording & Playback

~720p

1080p

1440p

1944p

2160p

Realtime (480/400fps)

Realtime (480/400fps)

1440p (240/200fps)

1944p (160fps)

2160p (120fps (for Analog Input), 240fps(4K2K lite for EXSDI))

Video Codec

H.265 / Dual Stream

Camera Input

No of Ports(BNC)

16

Type and Port

HD-SDI 1.5G / EX-SDI 1.0 / EX-SDI 2.0 / HD-TVI / AHD / HD-CVI / D1 (NTSC/PAL)

Resolution

720p25/30, 720p50/60, 1080p25/30, 1440p15/25/30, 1944p20, 4K2K15

Control

Analog Camera: UTC Supported for All Channels

SDI Camera: UTC Supported for one channel only,  UTC for All Channels is optionally supported

IP Hybrid

No of IP Camera

Up to 16

Protocols

ONVIF or Vendor Specific

Live Display Performance

Realtime Display with the D1/VGA 2nd Stream of Camera

4K2K 30fps for single channel display mode

Rec Performance

480fps@4K2K + 480fps@D1/VGA

Monitor Output

Main Monitor

Up to 4K30 for HDMI and Up to 1080p60 for VGA

SPOT Monitor

NTSC/PAL (HD SPOT to VGA optionally)

Multiple Ch View

1,4, (6,7,8,9, (10,13,16) ) for both live and playback

Audio In/Out

-

4 Line-in / 1 Line-out & Audio on HDMI

Alarm In/Out

-

16/1

Storage

SATA

2 (4 + 1 eSATA as optional with Big Case)

Archive

Backup Device

USB Device(HDD, Thumb Drive), NAS & Remote via Network

Multiple channel

Raw Data with Embedded Player

AVI

Embedded AVI formatting

USB Port

-

1 x USB2.0 at front & 2 x USB2.0 at Rear

System Control

-

USB Mouse

Network

Port

10M/100M/1000M (Ethernet) + 10M/100M/1000M (Local)

Protocols

DHCP, DDNS, P2P, uPNP, HTTP, NTP, SNMP, SMTP,  Push Notification (iOS/Android), ONVIF

No of Client

Max. 4

Network Service

-

ns.dynamicmv.com/P2P server/Relay Server/Push Server/E-mail Service (Public server)

Network Streaming

Live

Playback

Variable Resolutions, Quality Levels, and Frame Rates

Dual Streaming

Multi-Language

-

Support

RAID(Mirroring)

-

Configurable Dual Recording

Search

-

Calendar/Timeline/Virtual Jog Shuttle/Event/Panorama/Smart/USB Backup Device

Event

Event Type

Motion Detection, Alarm in, Video Loss, HDD S.M.A.R.T Status, HDD Error, Recording Status, POS

Notification

Action

E-Mail with snapshot, Buzzer, Relay, Push Notification

PoS I/F

-

Extendable up to 8 PoS Interface (Customizable)

Health Checking & Report

-

Periodical E-mail Report for HDD&Recording Status with various system information

Remote SW’s

-

RMS / Web / Android / iOS / macOS

Power

-

Adaptor (12V/5.0A), 12V/9.0A for 5 SATA Option

Operating Env.

-

-5~45°C / 20~80% RH

Dimension (WxDxH, mm)

-

340x302x60
